RME Audio Interface (DIGIFACE AVB)

$1,029.31

Brand RME
Compatible Devices Personal Computer
Number of Channels 256
Item Dimensions LxWxH 12 x 7 x 4 inches
Operating System Windows

  • Work clock I/O and bus power – PC
  • Transfer up to 256 channels of audio between PC and network
  • Additional headphone output allows high quality monitoring
  • A glance into the future of audio network technology

Description

Developed by RME, Digiface AVB is a glance into the future of audio network technology. The device uses AVB, an open protocol developed by the IEEE, to transfer up to 256 channels of audio between PC and audio network. An additional headphone output allows high quality monitoring.


From the manufacturer

Digiface AVB 256-Channel 192 kHz USB Audio Interface

Digiface AVB

Digiface AVB

Digiface AVB

Developed by RME, Digiface AVB is a glance into the future of audio network technology.

The device uses AVB, an open protocol developed by the IEEE, to transfer up to 256 channels of audio between PC and audio network.

An additional headphone output allows high quality monitoring.

Digiface AVB

Exploring new Ways to transport Audio

RME’s Digiface AVB showcases how audio can be transferred from the PC into the network and back using the AVB protocol stack. While Apple’s Mac OS has support for AVB already built in, the Digiface AVB also brings this capability Windows based PCs. Equipped with USB 3, it allows you to stream 128 channels of audio with sampling rates up to 192kHz into the AVB network and another 128 channels back.

My Mix

AVB & Dante Network Solutions by RME Audio

Channels are organized in streams of configurable size from 2 to 32 channels, which enables connections to all available AVB audio devices on the market (comprehensive compatibility tests pending). The accompanying software package comprises an AVDECC controller, which provides essential functions to discover all AVB devices in a network and manage connections of incoming and outgoing streams. Basic monitoring capabilities are built in. TotalMix FX enables comprehensive routing and monitoring options.

TotalMix FX and TotalMix Remote

Like all the latest RME interfaces, the Digiface Series also includes the powerful digital real-time mixer TotalMix FX. It allows for practically unlimited mixing and routing operations, with all inputs and playback channels simultaneously, to any hardware outputs.

The Digiface Series includes a dedicated Control Room section with Talkback, Main/Phones, fader groups, mute groups, complete remote controllability via Mackie or OSC protocol, and much more. The Digiface Series does not support DSP based effects (FX) like EQ or reverb.

Additionally RME’s latest software, TotalMix Remote, enhances the power of RME interfaces by enabling remote control via iOS, PC or Mac. With a straightforward set up process — simply enter the IP address of the computer you would like to control with TotalMix Remote and get going — users can quickly adjust any aspect of TotalMix FX on a host system while walking around the studio with their tablet, or from a control room located elsewhere in the facility.

Additional information

Weight 1.4 kg
Dimensions 12 × 7 × 4 cm
Item Weight

1.4 pounds

Product Dimensions

12 x 7 x 4 inches

Country of Origin

Germany

ASIN

B07JP2M3G2

Item model number

DIGIFACE AVB

Date First Available

November 16, 2018

Compatible Devices

Personal Computer

Operating System

Windows

Manufacturer

RME
