NDI HDMI Encoder, TBS2603SE NDI|HX Supported Professional HD H.264 H.265 HDMI Video Encoder Support HTTP HLS m3u8 RTP UDP

(10 customer reviews)

$269.00

Compatible Devices Cameras
Connector Type HDMI
Color NDI HDMI One Channel
Item Dimensions LxWxH 3.9 x 2.4 x 0.79 inches
Brand TBS

  • NDI|HX SUPPORT: NDI is a registered trademark of NewTek, TBS encoder has integrated native NDI|HX support which allows to send your HDMI video source through your local network, over Ethernet for use with other NDI compatible systems.
  • HD H.265/H.264 HDMI ENCODER: Encode video streams from any HDMI video source to various media streaming servers, it generates an H.264/H.265-encoded stream output and the AAC, Mp3 audio format
  • WEBPAGE CONTROL: Flexible and friendly webpage control, easy to check and control the status of the device.
  • MULTIPROTOCOL OUTPUT: Compliant with HTTP HLS RTMP(RTMPS) RTSP UDP SRT protocols, each channel has multiple protocols for outputting
  • NDI UPDATE: NDI HAS RELEASED THE LATEST FIRMWARE, CUSTOMERS WHO HAVE ALREADY PURCHASED PLEASE CONTACT US IF NEED TO UPDATE

Description

ANY PROBLEM WITH NDI PLEASE CONTACT US BEFORE RETURNING, WE WILL PROVIDE THE BEST TECHNICAL SUPPORT TO HELP YOU SOLVE THE PROBLEM

NDI|HX is a registered trademark of Newtek, Inc.

TBS Encoder has been integrated native NDI|HX support which allows to send your HDMI video source through your local network, over Ethernet for use with other NDI|HX compatible systems. It helps to connect your video cameras and other devices to your live production system, video applications or streaming devices

Features:
Flexible and friendly webpage control
Visual input (Preview)
AAC,MP3, MP2, PCMA audio encoding
Bitrate of output video stream is adjustable from 500kbit/s to 20Mbit/s
Support HTTP HLS(m3u8) RTP/UDP Unicast Multicast RTSP RTMP/RTMPS SRT
Support insert Logo, Text, Mosaics Or Time to the video
Support output displayed video resolution and frame rate setting(max 1920x1080P@60fps)
Support HDCP and HD blue-ray
Stable and effective, support 7 x 24h working time

Video:
Input: 1x HDMI 1.4
Input Resolution: 1920x1080P_50/60HZ; 1920x1080I_50/60HZ; 1280x720P 50/60HZ; 720×576; 640×480, and etc.
Ouput Resolution: 1920×1080@60fps; 1680×1050; 1280×720; 1024×576; 850×480; 720×576; 720×480; 640×480;480×360;360×240; auto; customized and etc.
Encode: H264 base line, H264 Main, H264 High, H265 Main
BitRate: 0.5Mbps-20Mbps
BitRate Control: CBR, VBR, AVBR,FIXQP
Protocol: SRT, HTTP, HLS, RTSP, RTP/UDP Unicast/Multicast, RTMP(RTMPS), SRT

Audio:
Encoding: AAC, MP3, MPEG2, PCMA
Sampling rate: 16K, 32K, 44.1K, 48K
Sampling precision: 16 bit
BitRate 32Kb/s ~ 256Kb/s

Network Stream IN:
Video: H264, H265
Audio: MPEG2, MP3, AAC

NDI Interface:
NDI Channels enable
NDI|HX output stream being detected automatically
SystemEthernet/RJ45: 1000 Base-T Ethernet interface
Supported System: Windows XP/VISTA/SERVER/WIN7/WIN10; Linux; MAC OS
Control: webUI

Additional information

Weight 1.03 kg
Dimensions 3.9 × 2.4 × 0.79 cm
Product Dimensions

3.9 x 2.4 x 0.79 inches

Item Weight

1.03 pounds

ASIN

B0833ZS3ZG

Item model number

TBS2603SE

Date First Available

December 1, 2019

Country of Origin

‎China

Manufacturer

TBS Technologies International LTD

10 reviews for NDI HDMI Encoder, TBS2603SE NDI|HX Supported Professional HD H.264 H.265 HDMI Video Encoder Support HTTP HLS m3u8 RTP UDP

  1. Bill Shanahan

    Good for the price but needs active cooling and a mount for meUsed to feed NDI|HX from camera hdmi for baseball game streaming – Southern US and hot in summer.Outside in ambient temp of about 85-95 F and placed in the shade – runs about 51 C. Drops connection – stuttering, some tearing and needs a couple of restarts per night. Google search on specs shows 0-45 C temp range in some page summaries but no mention of range when on sites or viewing manual. Manual shows images of device running 76 C (168 F – Ouch!).Stuck a 60 mm EC fan on top and dropped temp by 5-10 C – rock solid whole night. Will modify the case postseason and make fan install more permanent and efficient.Also epoxied a 1/4 mount to bottom. Much easier to place.Still seem to be worth it with some modifications.

  2. Ian McNabb

    Nice little boxBought this a few months ago when I could not get a USB capture device. In addition to the HDMI capture, it lets you open a network stream and convert to NDIHX. You can do 1 1080p60 encode or instead you can capture from HDMI AND a separate network stream simultaneously at 1080p30. I have been using this feature so I can convert the H264 program stream and the HDMI multi-viewer output from my switcher via NDIHX. There are a whole bunch of protocols and encoding parameters you can mess with via the webpage interface. Quality looks good, and with the right player i can get about half a second of latency. Nice little box.

  3. Amazon Customer

    Surprisingly for the price – it works almost exactly as describedPros:1/2 second latency with proper player settings.Very small. A 12v POE Splitter can be used to power this over EthernetSRT works as expected. You will not find a lower priced device with SRT Support.Cons:NDI is removed in newer versions. NDI 4.0 was not supported in older version.Heat – It runs warm. Do not stack them.

  4. Phil

    great inexpensive NDI converterI got 2 of these units to convert DSLR Cameras to an NDI feed to be used for broadcast. They work great, I received an older model that hadn’t been converted to NDI and the seller was great about walking me through the Firmware update and putting the codes in to turn on the NDI features.I highly recommend this unit and this seller

  5. Convenient Technology Services

    Device gets hot, but easy to setup and worksAside from the device getting real hot that you can’t leave it on any plastic, and the output video delay; the device was easy to setup and worked.

  6. Kirk C

    Very Pleased with this Purchase.Great little NDI converter. Used it to convert HDMI to NDI on a Camcorder. Used instead of a capture devices. Works great with Vmix to grab the signal for live broadcast. Tech support was very helpful when needed.

  7. Philip Vlasov

    Great ProductEasy to connect, Easy to operate. Awesome. Love it! Tested all Streams Works PERFECT! Simply Amazing!

  8. Amazon Customer

    its an amazing device for $200, supporting NDI & SRTIts really great, easy to configure and cheap. I’ll be using this for broadcast NDI and also for remote SRT broadcasts with a hotspot.

  9. RK

    Perfect way to get an HDMI signal to an NDI network!I bought 2 of these to connect cameras to an NDI broadcast for zoom. They work perfectly!

  10. Sophia&Mia

    Video encoder worksWorked as described to the letter
