Behringer Eurorack Pro RX1202FX Rackmount Mixer with Effects

(10 customer reviews)

$349.00

Brand Behringer
Number of Channels 12
Item Dimensions LxWxH 18.98 x 5.24 x 5.91 inches
Item Weight 6.7 Pounds
Connectivity Technology Auxiliary
  • 10-ch Mic/Line Mixer with 8 Mic Inputs
  • 2 Control Room Outputs
  • Built-in FX Process
  • 12 Line Inputs
  • 2 Main Outputs

Description

BEHRINGER EURORACK PRO RX1202FX

Premium 12-Input Mic/Line Rack Mixer with XENYX Mic Preamplifiers, British EQ’s and Multi-FX Processor

  • Premium ultra-low noise, high headroom analog 3U rack mount mixer
  • 8 state-of-the-art XENYX Mic Preamps comparable to stand-alone boutique preamps
  • Neo-classic “British” 2-band EQs for warm and musical sound
  • Studio-grade FX processor with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
  • Switchable +48 V phantom power for condenser microphones
  • 4 additional balanced high-headroom line inputs
  • CD/Tape inputs assignable to Main mix or Control Room/Phones outputs
  • 2 Aux sends per channel: 1 pre fader for monitoring applications, 1 post fader for internal FX or as external send
  • Separate Control Room, Phones and stereo CD/tape outputs
  • Balanced Main mix outputs with gold-plated XLR connectors
  • Long-wearing 60-mm logarithmic-taper faders and sealed rotary controls
  • “Planet Earth” switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
  • High-quality components and exceptionally rugged construction ensure long life
  • Conceived and designed by BEHRINGER Germany

Looking for a versatile line/mic mixer that fits in a rack AND eliminates the need for tons of outboard gear? The 12-channel RX1202FX is not only rack mountable, but comes loaded with a 24-bit multi-FX processor and 8 built-in studio-grade IMP “invisible” mic preamps. This mixer works perfectly for small bands or churches, business conferences with both microphone and A/V equipment as well as sub-mixing keyboards, drums, samplers or multiple vocal mics. It’s also the ideal choice for monitoring multi-track recording projects.

Channel Some Serious Mojo

Sometimes you feel like a mic…or a sampler…or a drum machine. Sometimes you don’t. Whatever the situation calls for, the RX1202FX is ready to accommodate. Each mono channel (1-8) features an XLR input, a balanced 1/4″ mono input and an INSERT jack for patching external signal processors directly into the channel. Mono channels feature a TRIM control and CLIP LED to adjust the input gain; a two-band EQ (HIGH, MID and LOW controls); FX control to determine how much of an effect to apply to the channel; a PAN control; and a smooth 60mm fader to determine the channel’s level in the mix. Stereo channels (9-12) feature left and right balanced line level 1/4″ inputs and the same front panel control as their mono counterparts. And, as mentioned above, they can be used as mono inputs themselves.

Taking Control

Smooth 60 mm faders and intuitive rotary dials make it quick and simple to create a killer mix. The MAIN MIX fader adjusts the volume of the main output signal while the dual 4-segment LED ladder display gives a visual representation of the signal level. The PHONES jack features a dedicated PHONES/ CONTROL ROOM dial for adjusting headphone volume. Push CD/TAPE TO MIX to add backing tracks from an MP3 or CD player, or to isolate a click track or scratch track in headphones while recording.

On the back panel, the LEFT and RIGHT MAIN OUT XLR jacks can be used to feed a recording device or PA system. For live performances, keep pre-recorded music cued up for between-set breaks by connecting a CD player or MP3 player via the stereo CD/TAPE IN jacks. If the band wants a recording of their performance, send signal to a recording device such as a mini-disc recorder via the CD/TAPE OUT jacks. Use the MON AUX SEND to send signal to floor monitors in a live setting, or to a headphone amp in a recording setting. When it’s time for playback of recorded material, send signal to studio monitors through the CTRL OUT jack.

If a recording session or live performance calls for an effect not programmed in the onboard FX processor, send signal to an outboard effects unit via the FX AUX SEND, then feed the signal back to the RX1202FX through the AUX RETURN jacks.

Effects, Effortlessly

The FX/CTRL section puts sophisticated digital effects at your fingertips. Use the PROGRAM dial to scroll through the effect presets, then use the FX TO MAIN dial to govern how much of the effect is heard in the summed signal of the mixer. Push FX SOLO to hear only the effects signal in your monitors or headphones.

Superior Sound, Unparalleled Value

It’s nearly impossible to find a rack-mountable mixer loaded with the inputs, mic preamps and digital effects found in the RX1202FX. And with a price tag that’s well below what you would pay to purchase all these tools separately, the RX1202FX is the smartest way to make your studio, live band, church or conference sound like a million bucks.


From the manufacturer

RX1202FX V2

RX1202FX V2

Premium 12-Input Mic/Line Rack Mixer with XENYX Mic Preamplifiers, British EQ’s and Multi-FX Processor
  • Premium ultra-low noise, high headroom analog 3U rack mount mixer
  • 8 state-of-the-art XENYX Mic Preamps comparable to stand-alone boutique preamps
  • Neo-classic “British” 2-band EQs for warm and musical sound
  • Switchable +48 V phantom power for condenser microphones
  • 4 additional balanced high-headroom line inputs
  • CD/Tape inputs assignable to Main mix or Control Room/Phones outputs
  • Separate Control Room, Phones and stereo CD/tape outputs

RX1202FX V2

RX1202FX

Sonically Superior Mic Preamps

Sublimely Musical British EQ

Effective FX

RX1202FX

The rack-mountable, 12-Input RX1202FX mixer enables you to effortlessly achieve premium-quality sound, thanks to 8 onboard studio-grade XENYX Mic Preamps, 2 stereo Line Inputs and ultra-musical “British” channel EQs. Add to this our 24-Bit Multi-FX processor with 100 awesome presets including studio-class reverbs, delays, pitch shifter and various multi-effects – and the RX1202FX becomes an incredibly-versatile mixer for your live performances. Ideally suited for musicians, houses of worship and a wide variety of business applications, the incredible RX1202FX is also perfect for sub-mixing keyboards, drums or multiple vocal mics – and is an absolute “must-have” for monitoring your multitrack recording projects!

Sonically Superior Mic Preamps

Our legendary, high headroom XENYX mic preamps have been praised by audio engineers all over the world. These state-of-the-art mic pres represent a major step in the evolution of audio technology – and they can easily hold their own, even when compared to the most expensive stand-alone mic preamps. XENYX preamps off er a staggering 130 dB of dynamic range, with a bandwidth that extends from below 10 Hz to well above 200 kHz. Armed with these outstanding mic preamps, the RX1202FX provides such transparent, crystal-clear performance you just might think someone upgraded your mics while you weren’t looking.

Sublimely Musical British EQ

The British consoles of the 1960s and ‘70s changed the sound of rock and roll – without them the British Invasion might not have happened. Those legendary mixing desks soon became the envy of engineers and producers all over the world. The channel EQ on our RX1202FX mixer is based on that very same circuitry, allowing you to imbue signals with incredible warmth and detailed musical character. Even when applied generously, these equalizers exhibit sweet forgiveness and superb audio quality.

Effective FX

Every RX1202FX mixer features our 24-Bit Multi-FX processor, with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects. Complete with highly-accurate Signal and Clip LEDs, these effects are instantly available at your fingertips via the Program selector control.

RX1202FX V2

Taking Control

Panel Discussion

Amazing Performance and Value

Taking Control

Smooth 60 mm faders and intuitive rotary dials make it quick and simple to create a great mix. The Main Mix fader adjusts the volume of the Main Output signal, while the dual 4-segment LED ladder display gives a visual confirmation of the signal level. The Phones jack features a dedicated Phones/Control Room dial for adjusting the volume. Push CD/Tape to Mix to add backing tracks from an mp3 or CD player, or the CD/Tape To Ctrl to isolate a click or scratch track in the headphones during recording.

Panel Discussion

On the RX1202FX’s rear panel, the Left and Right Main Out XLR connections can be used to feed the mix to a recording device or PA system. For live performances, keep pre-recorded music cued up for between-set breaks by connecting a CD or mp3 player via the stereo 2-Track In jacks. If the band wants a recording of their performance, you can send the signal to a recording device via the 2-Track Out jacks. Use the Mon Aux Send to send the monitor bus signal to your floor monitors in a live performance, or to a headphone amp in a recording session. When it’s time for playback of the recorded material, just send the signal to your studio monitors via the Ctrl Out jack.

Amazing Performance and Value

No matter what your audio mixing needs, the RX1202FX provides the performance and features that can take your talent to the next level. Professional sound quality, our legendary XENYX mic preamps, British EQs, 24-Bit Multi-FX Processor and USB connectivity make EURORACK PRO RX1202FX ideal for both your live gigs and recording.

Additional information

Weight 6.7 kg
Dimensions 18.98 × 5.24 × 5.91 cm
Item Weight

6.7 pounds

Product Dimensions

18.98 x 5.24 x 5.91 inches

ASIN

B000H58HN0

Item model number

RX1202FX

Date First Available

October 2, 2001

Color Name

Slvr/Blk

Power Source

Corded Electric

Wattage

18 watts

Manufacturer

Behringer

10 reviews for Behringer Eurorack Pro RX1202FX Rackmount Mixer with Effects

  1. steve

    It fit the bill, but there are drawbacks…First and Foremost, this unit works perfectly, functions as designed, and was packaged well. It is 3 rack space and fit into the 3 rack space opening I had.Cons: That being said, I did my first gig with this. Basically the customer needed an announcing PA and wanted a live music for lunchtime. Again, while it functions perfectly, the drawback was that the channels DO NOT have mute buttons. If you need to pull a channel out of the Main mix and the monitor Mix, you need to pull the fader totally off and turndown the monitor pot. Both. Then you need to remember where you had them in the mix when you bring them back. A mute button would have made this much better. While this is not a deal breaker for me, it would be most convenient if mute buttons would be incorporated.Pros: While I’m not a Behringer fan, this units performance was good. The mic pre’s have good headroom. The digital effects unit built in was adequate for the task. This mixer did make my small venue system self contained. I just plug in power, plug in speakers, and plug in Mic’s/Lines and I’m up and running. From that standpoint, it does what I needed. It does perform better than expected.The inconvenience of the mutes was enough to put this at 4 stars. But it does work well other than that.

  2. Manuel

    originally purchased to use as a sub mixer for my drums (will try that this weekend) and if it performs as well as it did for vocals i will be very satisfied..2 gigs as a PA (*using Behringer powered speakers) performed as expected…simple, compact, and the effects were quite suitable for both vocals and acoustic guitars…durability is still to be determined…originally purchased to use as a sub mixer for my drums (will try that this weekend) and if it performs as well as it did for vocals i will be very satisfied…reasonably priced, and frankly, impressive (cost / benefit…there are better mixers yes, but this seems to meet my needs)

  3. Bobby

    Behringer Rack MixerI bought this as a simple control room mixer for my new voice-over studio. I needed something compact and shallow in depth in order to fit my current mixing desk. It is used mostly for control room monitoring/playback and to feed a push-to-talk system to my voice-booth. I would’ve liked it better if it would have included individual channel mute buttons, but I knew that going in, so I can’t really fault Behringer for that here. It’s very quiet, everything works, it seems well-built, and it fits the physical requirements of my new system.I own several Behringer products that I have had a good experience with for many years. We’ve all read some of the bad reviews that company has received, but all I can say here is that I’m very happy with this purchase.

  4. Jackie Johnson

    This was perfect mixer for a an installation in rooms where several …This was perfect mixer for a an installation in rooms where several inputs are needed but are used separately and don’t need an experienced operator. Good sound quality, and lots of inputs. The one negative is that the power button is located in the back of the unit, thus when installed in a rack, the switch is not easily accessible.

  5. Empire Video Productions

    Good board, I like itIf I had one wish – it would be a mute for all channels – but good rack mixer – I use it in my live web streaming rack gear

  6. W. Lynch

    I was skeptical, but it’s been great so farAlways nervous about Behringer quality, but it’s worked perfectly so far. I use it for mixing several mic’s for a drumset and adding some effects. Hopefully it lasts forever!

  7. Jeremiah J. Bowen

    Behringer, you have failed me!I hate that I have to drop my rating. I started using the Eurorack because of its 3u format. The first 4 that I owned were fantastic. Granted, like many of Behringer’s products, being economically priced you may need to make a return to get a “perfect” product, but overall the savings compensated for this inconvenience.I bought a new board in August to replace a set of equipment that was stolen. The unit immediately produced a humming sound. I did the basic trouble shooting that might fix the issue without voiding warranty, but it persisted. This one was one to return and swap.Between a combination of boards purchased at a local retailer and those from Amazon, I wound up the 5 units and finally wound up with one with LESS “hum” than the others. Once the volume was up A LOT it could drown out the interference.It has not been 4 months since this board was put into commission and the interference had grown to the point of shameful. It seems that the quality control for this product is no longer a concern to Behringer.I will now be looking into other options. I hope that your experience is not like mine and wish you well in your sound adventures.Jeremiah BowenLive Circuit Karaoke and EntertainmentSince 2003UPDATE…. ALLEN AND HEATH! Even though i had to change the format, the sound is amazing!

  8. Dave S

    PERFECT small gig or monitor mixerThis is exactly what we needed for a compact mixer. We used it as a monitor mixer and chain the mic signals to the main board. This thing feeds our in ears and gives us great sound in a tiny space with minimal mess. Sound is excellent and for the price there really isn’t anything like it. This is the third Behringer mixer I’ve bought in a pinch and the third time I’ve been extremely happy.

  9. August Will Decay

    AFFORDABLE QUALITY A RARE COMBINATION *****THIS IS MY SECOND MIXER OF THIS EXACT MODEL AND BEHRINGER MAKES AFFORDABLE AND ABOVE AVERAGE PRODUCTS THAT PERFORM WELL. MY ADVICE TAKE CARE OF IT AND IT WILL LAST A LONG TIME, I HAVE SEEM BEHRINGER PRODUCTS BREAK DOWN BUT THATS FROM ABUSE. I HAVE HAD BEHRINGER PRODUCTS FOR TEN PLUS YEARS STILL LOOKING WORKING AND SOUNDING LIKE NEW. A GOOD MIXER FOR A GOOD PRICE. I RECOMMEND FOR SURE. *****

  10. gabbysurfer

    unit works awesome…never had a problem ….it is a work horse
