Audiotek AT-EQ700 1/2 Din 7 Band Car Audio Equalizer EQ w/Front, Rear + Sub Output | Auxiliary Stereo RCA Input – 3 Stereo RCA

(4 customer reviews)



This equalizer is a 7-band stereo equalizer / crossover specifically created for the mobile environment. It provides powerful features in a compact size: – Seven equalization bands (63Hz, 125Hz, 315Hz, 750Hz, 2.2kHz, 6kHz, and 12kHz), each frequency is adjustable from -12 to + 12dB (-15 to +15dB for subwoofer frequencies) – Subwoofer output uses a built-in 18dB per octave electronic crossover fixed at 60Hz or 120Hz – Three stereo RCA outputs to drive front, rear, and subwoofer audio amplifiers – An auxiliary stereo RCA input for use with portable devices, such as an MP3 Player or DVD player – Separate controls for master volume, subwoofer volume (sub level), front/rear fader, and selection of main or auxiliary inputs – Extended frequency response from 20Hz to 30kHz with exceptional 100dB signal-to-noise performance – Gold-plated RCA connectors to ensure the best audio signal output – ISO mounting holes and removable trim ring for custom installation Technical Details: Graphic Center Frequencies: 63Hz, 125Hz, 315Hz, 750Hz, 2.2kHz, 6kHz, and 12kHz Boost/Cut: 12dBS/N Ratio: 100dB Frequency Response: 10Hz ~ 50kHz +/-1dB Maximum Output Voltage: 7V THD: 0.005% Input Sensitivity: 50mV ~ 3V Head Room: 20dB Input Impedance: 20kOhms Output Impedance: 2kOhms Stereo Separation: 82dB/1kHz Operating Voltage: 11V ~ 15V Negative Ground Size: 7 x 4 1/8″ x 1 inches

Additional information

Weight 680 kg
Dimensions 16.3 × 4.9 cm
Package Dimensions

‎ 21.2 x 16.3 x 4.9 cm; 680 Grams

Date First Available

‎ 22 June 2012


‎ B008D64VQW



4 reviews for Audiotek AT-EQ700 1/2 Din 7 Band Car Audio Equalizer EQ w/Front, Rear + Sub Output | Auxiliary Stereo RCA Input – 3 Stereo RCA

  1. Jim M.

    I have had no problems with mine
    if i turn the amp way up and then adjust the eq vol its harder to get any clipping (distortion). I have not gotten any clipping from the line-in to the eq. Its a balance between amp vol (background noise if to high), eq vol, eq band levels, and a line-in.

  2. Ike

    Horrible distortion as volume increases

  3. Todd bell

    Don’t do it!!!!!!!!
    Shipping was great however it’s a bottom of the barrel EQ! do yourself a favor and spend an extra 10 dollars to buy anything other than this one. Very cheaply made and to use the “fade” you have to add another amp witch defeats the the point of purchasing it. The other issue is “radio/cassette” or “cd” button! Cassette!!! Really!!!! also no fuse to protect your vehicle or the component.

  4. John

    Piece of crap , save your money
    No work
